| Brightfield binocular microscope with IOS N-PLAN (Infinity Corrected) objectives, rackless stage and combining the exclusive X-LED3 with ALC (Automatic Light Control) for great-looking, rich and high-quality view. |
| Observation mode: Brightfield. |
| Head: Binocular, 30° inclined, 360° rotating (when ALC cable is unplugged). |
| Interpupillary distance: Adjustable between 48 and 75 mm. |
| Dioptric adjustment: On the left eyepiece tube. |
| Eyepieces: WF10x/20 mm, high eye-point and secured by screw. |
| Nosepiece: Quintuple revolving nosepiece, rotation on ball bearings. |
| Objectives: IOS N-PLAN 4x/0.10 IOS N-PLAN 10x/0.25 IOS N-PLAN 40x/0.65 IOS N-PLAN 100x/1.25 (Oil/Water) All with anti-fungus treatment. |
| Specimen stage: Double layer rackless mechanical stage, 233×147 mm, 78×54 mm X-Y range. |
| Focusing: Coaxial coarse (adjustable tension) and fine focusing mechanism with limit stop to prevent the contact between objective and specimen. |
| Condenser: Abbe N.A. 1.25, with objective-coded iris diaphragm, focusable and centerable. |
| Illumination (Fixed Koehler type): X-LED3 with white 3.6 W LED (6,300K) and brightness control. ALC system. Multi-plug 100-240Vac/6Vdc external power supply |
Microscope Binocular Head (Brightfield) B 382PHi ALC Optika Italy
৳ 199,000.00
Binocular 360°rotating 30° inclined
Eyepiece: Wide Field 10X/20 mm
Model: B 382PHi ALC
Brand: OPTIKA
Country: ITALY
