| Features: |
| To incubate samples at a constant, desired temperature during the reaction period, a thermostat cabinet is necessary. WTW offers thermostat cabinets in various sizes with a variably adjustable temperature range of 10°C-40 °C (50 °F-104 °F) and a power supply of 230 V/50 Hz. Temperature accuracy lies at ±1 °C deviation from the set temperature. Because the samples must be stirred, the thermostat cabinets |
| are fitted with internal power sockets. 2-4 shelves are available, according to the thermostat cabinet size, thus enabling simultaneous temperature control of up to |
| 48 standard BOD samples or 4 IS 12 or IS 6-Var stirrer platforms. The largest model, TS 1006-i is especially suited for special applications, as the space between the 4 shelves allows for 1.5 l vessels or flasks with side nozzles. The sizes TS 608/2-i aTS 608/4-i are available with transparent insulating glass doors and are especially suited for use with the OxiTop® Control system. Data can be recalled through the closed glass door, to avoid temperature fluctuations caused by opening the door. |
| Technical Specifications of Thermostat Cabinet (BOD Incubator): |
| Model: TS 608/G 2-i |
| Shelves: 2 |
| Number of Samples: 2 x 12 BOD standard |
| Glass door: Yes |
| Temp. control range +10 °C +40 °C (50 °F 104 °F) ±1 K; adjustment interval: 1 °C |
| Ambient temperature Operation: +10 °C … +32 °C (50 °F … 89.6 °F) (Climate class SN); Storage: -25 °C … +65 °C (-13 °F … 149 °F) |
| Gross contents: 180 L |
| Dimensions (H x B x D) outside: 850 x 620 x 600mm |
| Dimensions (H x B x D) inside: 734 x 513 x 433mm |
| Weight: 37 Kg |
