Advantage: absolute encoding, international level, ranging from ultra fast (0.8 seconds)
Measuring range: 5000 m single prism
Accuracy: ranging 2+2ppm, 2″
Standby: continuous ranging 10 hours
Waterproof grade: IP56
Laser ranging
Technical Index:
Single prism 5.0Km
Measuring time accuracy of 0.8 seconds, 0.5 seconds
The number shows the maximum: 99999999.9999 Min: 1mm/0.1mm (set)
The accuracy of a prism: 2+2ppm free prism: 3+2ppm
Automatic correction of meteorological correction input parameters
Correction of the input parameters of the prism constant
Angle measurement
Absolute encoding style angle measurement
Disc diameter 79mm
Minimum reading 0.1”/1”/5”
Accuracy 2”
Detection method level set: the diameter of the vertical plate: right
Telescope
Imaging positive
Tube length 154mm
Objective: the effective aperture telescope 45mm range: 50mm
Magnification 30 x
Viewing angle of 1 degrees 30′
Resolution 3”
Minimum focus distance 1m
Automatic vertical compensator
System liquid electronic sensor compensation
Working range of + 4′
Accuracy 1”
Level
Pipe level 30”/2mm
Round level 8”/2mm
Optical alignment
Imaging positive
Magnification 3 x
Focus range 0.5m~ ~
Viewing angle of 5 degrees
Laser to medium
On the accuracy of 1.5mm 1.5m
Laser point diameter 2.5mm 1.5m
Brightness adjustment function
Infinite bit micro screw
Spiral number 1 horizontal /1 vertical
Display part
Type double side, 6 lines of Chinese display
Airborne battery
Power rechargeable nickel hydrogen battery
Voltage direct current 6.0V
Continuous working time 10 hours
Size and weight
Size 190mm x 200mm x 350mm
Weight 5.8kg
Humanized setting
Automatic correction of 2C correction software
Waterproof and dust level IP56
