| Model JSBS-5000 Bio-Suction is an economical, compact and portable solution for aspirating tissue culture samples, aqueous solutions, buffers, culture media residual suction. Two stage oil-free piston pump provides a high flow rate and powerful vacuum aspiration. 4000 cc autoclaveable glass suction bottle with over flow protection stopper protects liquid ingested into the pump system which may lead to the valve failing or a diaphragm rupturing. Pump automatically shut down when full and a hydrophobic PTFE inline filter further protects the pump from aerosol ingestion. Hands free foot pedal switch provides convenient On/ Off operation. Built-in silencer provides comfortable noise-free operation |
| Technical Specifications: |
| Pumping Capacity: 20 liter / min |
| Ultimate Vacuum: 650 mmHg (-0.08 Mpa ABS) |
| Collection Bottle – |
| Capacity: 4000 cc |
| Material: Glass Bottle / W Cap |
| Utility: Cap with overflow protection Detachable Inlet / Outlet Fitting / w Cap |
| Pump Control: On / Off / Foot Pedal |
| Safety: ф50 mm Hydrophobic inline PTFE filter protects aerosol ingestion |
| Automatic pump shut off when bottle is full |
| Convenience: Built-in Silencer Portable carrying handle |
| Accessories included: Main body built-in vacuum pump system |
| Collection receiver bottle |
| ф50 mm inline PTFE filter |
| Foot Pedal |
| Silencer |
| Silicone Tubing |
| Dimensions:240 x 370 x 330 mm |
| Electrical Requirement: 220 VAC 50 / 60 Hz |
